| Specifications | |||
| Number of Pins: | 8 Pins | Key Position: | - |
| Left Connector: | Power | Right Connector: | - |
| AWG Gauge: | - | Connection Type: | Plug and unplug |
| Wires & Cables Length: | - | ||
| Material | |||
| Housing & Insulation: | PBT | Contacts: | Copper Alloy, 30µ Gold-Plated |
| Shell: | - | Sealing: | - |
| Shielding: | - | Overmolding: | - |
| Wires & Cables Conductor: | - | Wires & Cables Jacket: | - |
| Technical Characteristics | |||
| Rated Current: | 5A | Rated Voltage: | 500V |
| Rated Temperature: | -55°C ~ + 155°C | Flame Retardant Grade: | UL94V-0 |
| Insulation Resistance: | ≥ 1000 MΩ | Contact Resistance: | ≤ 30m Ω |
| Durability: | ≥ 5000 Times | Protection Grade: | - |
| Product Certification: | RoHS, REACH | Production Design Standards: | - |
